Dik Geurts Bora Corner

Energy efficiency class A
Product fiche Click for PDF-file
Model Freestanding
Fire view 2-sided
Shape Horizontal
Fuel Wood
Combustion system Combustion air from outside, Combustion air from living area
Suitable for passive houses
Glass window Standard glass, Infrared glass
Door type Hinged door
Control Manual control
S-Thermatik NEO
Colours Dark anthracite
Material Steel
Interior Vermiculite dark anthracite
Output net min. (kW) 4.0
Output net max. (kW) 9.0
Nominal heat output 6.7
Max. log length (cm) 36
Efficiency (%) 78.1
CO emission (%-13% O2) 0.09
Particulate Matter (mg/Nm3-13% O2) 18
OGC/CxHy (mg/Nm3-13% O2) 64
NOx emission (mg/Nm3-13% O2) 98
Built-in depth (mm) 450
Fire view width (mm) 440
Fire view height (mm) 380
Weight (kg) 110
Flue Top
Flue Ø (mm) 150
External air connection Base
Convection connection
230V necessary
