Dik Geurts Modivar 5

Energy efficiency class A+
Model Freestanding
Fire view Front
Shape Vertical
Fuel Wood
Combustion system Combustion air from outside, Combustion air from living area
Suitable for passive houses

Glass window Standard glass
Door type Hinged door
Control Manual control

Colours Dark anthracite
Material Steel
Interior Vermiculite natural
Output net min. (kW) 4.0
Output net max. (kW) 7.0
Nominal heat output 5
Max. log length (cm) 35
Efficiency (%) 82.0
CO emission (%-13% O2) 0.09
Particulate Matter (mg/Nm3-13% O2) 8
OGC/CxHy (mg/Nm3-13% O2) 62
NOx emission (mg/Nm3-13% O2) 78
Built-in depth (mm) 368
Fire view width (mm) 310
Fire view height (mm) 355
Weight (kg) 105
Flue Top, Rear
Flue Ø (mm) 125/130
External air connection Rear, Base
Convection connection

230V necessary
